CNC Vertical Milling Machine

The CNC-reinforced milling machine adopts a full-gear spindle box, and the spindle transmission part adopts gears with precision of more than 6 levels, with large torque, low noise, and high precision. With 12-speed speed control, it ensures strong cutting under different conditions.Optional Taiwan pneumatic tool lock mechanism, fast tool change, low labor intensity, and high efficiency. It can meet the needs of roughing and special-shaped processing of molds.

Get A Quote

PREV：CNC Vertical Machining Center NEXT：No next article

Description
Technical Parameters
Contact Us

●XKV1800 CNC vertical reinforced milling machine is suitable for rough and finish machining of most materials in different processes such as castings and steel parts.
●The machine adopts the enhanced fuselage structure, the reference guide adopts the overall super-audio hardening, and the matching surface is affixed with an imported guide soft belt to ensure the micro-wear movement of each feed component, and maintain high precision and high stability for a long time.
●All three axes of the machine are P3-level 50×P10 ball screws, and the assembly process of 2-end fixed pretension is used to strengthen the axial rigidity.
●Large stroke working space (1800mm vertical ×700mm horizontal ×750mm lifting), to meet the processing needs of general large parts.

Index	Unit	XKV1600	XKV1800
Workbench size	mm	2200×450	2200×600
Workbench saddle matching width	mm	450	500
Max. load of workbench	kg	1500	2000
T slot (number×width×distance)	mm	5×18×85	5×18×100
X-axis travel	mm	1600	1800
Y-axis travel	mm	600	700
Z-axis travel	mm	600	750
Spindle end to bench top	mm	50~600	100~850
Spindle center to column	mm	550	700
Bed rail width	mm	780	1100
Spindle taper hole size		NT50	NT50
Spindle speed	rpm	50~1720	50~1720
X-axis screw		4010	5010
Y, Z-axis screw		4006	5010
